Introduction

Ask somebody in the building industry to visually communicate the architecture of a building and you'll be presented with site plans, floor plans, elevation views, cross-section views and detail drawings. In contrast, ask a software developer to communicate the software architecture of a software system using diagrams and you'll likely get a confused mess of boxes and lines ... inconsistent notation (colour coding, shapes, line styles, etc), ambiguous naming, unlabelled relationships, generic terminology, missing technology choices, mixed abstractions, etc.

A software architecture sketch

A software architecture sketch

A software architecture sketch

A software architecture sketch

As an industry, we do have the Unified Modeling Language (UML), ArchiMate and SysML, but asking whether these provide an effective way to communicate software architecture is often irrelevant because many teams have already thrown them out in favour of much simpler "boxes and lines" diagrams. Abandoning these modelling languages is one thing but, perhaps in the race for agility, many software development teams have lost the ability to communicate visually.

Maps of your code

The C4 model was created as a way to help software development teams describe and communicate software architecture, both during up-front design sessions and when retrospectively documenting an existing codebase. It's a way to create maps of your code, at various levels of detail, in the same way you would use something like Google Maps to zoom in and out of an area you are interested in.

Google Street View

Like source code, Google Street View provides a very low-level and accurate view of a location.

Google Maps

Navigating an unfamiliar environment becomes easier if you zoom out though.

Google Maps

Zooming out further will provide additional context you might not have been aware of.

Google Maps

Different levels of zoom allow you to tell different stories to different audiences.

Although primarily aimed at software architects and developers, the C4 model provides a way for software development teams to efficiently and effectively communicate their software architecture, at different levels of detail, telling different stories to different types of audience, when doing up front design or retrospectively documenting an existing codebase.

The C4 model is an "abstraction-first" approach to diagramming software architecture, based upon abstractions that reflect how software architects and developers think about and build software. The small set of abstractions and diagram types makes the C4 model easy to learn and use.

Abstractions

In order to create these maps of your code, we first need a common set of abstractions to create a ubiquitous language that we can use to describe the static structure of a software system. The C4 model considers the static structures of a software system in terms of containers, components and code. And people use the software systems that we build.

Abstractions

A software system is made up of one or more containers (web applications, mobile apps, desktop applications, databases, file systems, etc), each of which contains one or more components, which in turn are implemented by one or more code elements (e.g. classes, interfaces, objects, functions, etc).



An example software architecture model

A visualisation of an example software architecture model, showing the hierarchical nature of the elements that make up the static structure.

Person

However you think about your users (as actors, roles, personas, etc), people are the various human users of your software system.

Software System

A software system is the highest level of abstraction and describes something that delivers value to its users, whether they are human or not. This includes the software system you are modelling, and the other software systems upon which your software system depends (or vice versa).

Container

A container represents something that hosts code or data. A container is something that needs to be running in order for the overall software system to work. In real terms, a container is something like:

  • Server-side web application: A Java EE web application running on Apache Tomcat, an ASP.NET MVC application running on Microsoft IIS, a Ruby on Rails application running on WEBrick, a Node.js application, etc.
  • Client-side web application: A JavaScript application running in a web browser using Angular, Backbone.JS, jQuery, etc).
  • Client-side desktop application: A Windows desktop application written using WPF, an OS X desktop application written using Objective-C, a cross-platform desktop application written using JavaFX, etc.
  • Mobile app: An Apple iOS app, an Android app, a Microsoft Windows Phone app, etc.
  • Server-side console application: A standalone (e.g. "public static void main") application, a batch process, etc.
  • Microservice: A single microservice, hosted in anything from a traditional web server to something like Spring Boot, Dropwizard, etc.
  • Database: A schema or database in a relational database management system, document store, graph database, etc such as MySQL, Microsoft SQL Server, Oracle Database, MongoDB, Riak, Cassandra, Neo4j, etc.
  • Blob or content store: A blob store (e.g. Amazon S3, Microsoft Azure Blob Storage, etc) or content delivery network (e.g. Akamai, Amazon CloudFront, etc).
  • File system: A full local file system or a portion of a larger networked file system (e.g. SAN, NAS, etc).
  • Shell script: A single shell script written in Bash, etc.
  • etc

A container is essentially a context or boundary inside which some code is executed or some data is stored. And each container is a separately deployable/runnable thing or runtime environment, typically (but not always) running in its own process space. Because of this, communication between containers typically takes the form of an inter-process communication.

Component

The word "component" is a hugely overloaded term in the software development industry, but in this context a component is simply a grouping of related functionality encapsulated behind a well-defined interface. If you're using a language like Java or C#, the simplest way to think of a component is that it's a collection of implementation classes behind an interface. Aspects such as how those components are packaged (e.g. one component vs many components per JAR file, DLL, shared library, etc) is a separate and orthogonal concern.

An important point to note here is that all components inside a container typically execute in the same process space.

Core diagrams

Visualising this hierarchy of abstractions is then done by creating a collection of Context, Container, Component and (optionally) Code (e.g. UML class) diagrams. This is where the C4 model gets its name from.

A System Context diagram

Level 1: System Context diagram

A System Context diagram is a good starting point for diagramming and documenting a software system, allowing you to step back and see the big picture. Draw a diagram showing your system as a box in the centre, surrounded by its users and the other systems that it interacts with.

Detail isn't important here as this is your zoomed out view showing a big picture of the system landscape. The focus should be on people (actors, roles, personas, etc) and software systems rather than technologies, protocols and other low-level details. It's the sort of diagram that you could show to non-technical people.

Scope: A single software system.

Primary elements: The software system in scope.
Supporting elements: People and software systems directly connected to the software system in scope.

Intended audience: Everybody, both technical and non-technical people, inside and outside of the software development team.

A Container diagram

Level 2: Container diagram

Once you understand how your system fits in to the overall IT environment, a really useful next step is to zoom-in to the system boundary with a Container diagram. A "container" is something like a server-side web application, single-page application, desktop application, mobile app, database schema, file system, etc. Essentially, a container is a separately runnable/deployable unit (e.g. a separate process space) that executes code or stores data.

The Container diagram shows the high-level shape of the software architecture and how responsibilities are distributed across it. It also shows the major technology choices and how the containers communicate with one another. It's a simple, high-level technology focussed diagram that is useful for software developers and support/operations staff alike.

Scope: A single software system.

Primary elements: Containers within the software system in scope.
Supporting elements: People and software systems directly connected to the containers.

Intended audience: Technical people inside and outside of the software development team; including software architects, developers and operations/support staff.

Notes: This diagram says nothing about deployment scenarios, clustering, replication, failover, etc.

A Component diagram

Level 3: Component diagram

Next you can zoom in and decompose each container further to identify the major structural building blocks and their interactions.

The Component diagram shows how a container is made up of a number of "components", what each of those components are, their responsibilities and the technology/implementation details.

Scope: A single container.

Primary elements: Components within the container in scope.
Supporting elements: Containers (within the software system in scope) plus people and software systems directly connected to the components.

Intended audience: Software architects and developers.

A UML class diagram

Level 4: Code

Finally, you can zoom in to each component to show how it is implemented as code; using UML class diagrams, entity relationship diagrams or similar.

This is an optional level of detail and is often available on-demand from tooling such as IDEs. Ideally this diagram would be automatically generated using tooling (e.g. an IDE or UML modelling tool), and you should consider showing only those attributes and methods that allow you to tell the story that you want to tell. This level of detail is not recommended for anything but the most important or complex components.

Scope: A single component.

Primary elements: Code elements (e.g. classes, interfaces, objects, functions, database tables, etc) within the component in scope.

Intended audience: Software architects and developers.

Supplementary diagrams

Once you have a good understanding of the static structure, you can supplement the C4 diagrams to show other aspects.

A System Landscape diagram

System Landscape diagram

The C4 model provides a static view of a single software system but, in the real-world, software systems never live in isolation. For this reason, and particularly if you are responsible for a collection of software systems, it's often useful to understand how all of these software systems fit together within the bounds of an enterprise. To do this, simply add another diagram that sits "on top" of the C4 diagrams, to show the system landscape from an IT perspective. Like the System Context diagram, this diagram can show the organisational boundary, internal/external users and internal/external systems.

Essentially this is a high-level map of the software systems at the enterprise level, with a C4 drill-down for each software system of interest. From a practical perspective, a system landscape diagram is really just a system context diagram without a specific focus on a particular software system.

Scope: An enterprise.

Primary elements: People and software systems related to the enterprise in scope.

Intended audience: Technical and non-technical people, inside and outside of the software development team.

A dynamic diagram

Dynamic diagram

A simple dynamic diagram can be useful when you want to show how elements in a static model collaborate at runtime to implement a user story, use case, feature, etc. This dynamic diagram is based upon a UML communication diagram (previously known as a "UML collaboration diagram"). It is similar to a UML sequence diagram although it allows a free-form arrangement of diagram elements with numbered interactions to indicate ordering.

Scope: An enterprise, software system or container.

Primary and supporting elements: Depends on the diagram scope; enterprise (see System Landscape diagram), software system (see System Context or Container diagrams), container (see Component diagram).

Intended audience: Technical and non-technical people, inside and outside of the software development team.

A deployment diagram

Deployment diagram

A deployment diagram allows you to illustrate how containers in the static model are mapped to infrastructure. This deployment diagram is based upon a UML deployment diagram, although simplified slightly to show the mapping between containers and deployment nodes. A deployment node is something like physical infrastructure (e.g. a physical server or device), virtualised infrastructure (e.g. IaaS, PaaS, a virtual machine), containerised infrastructure (e.g. a Docker container), an execution environment (e.g. a database server, Java EE web/application server, Microsoft IIS), etc. Deployment nodes can be nested.

Scope: A single software system.

Primary elements: Deployment nodes and containers within the software system in scope.

Intended audience: Technical people inside and outside of the software development team; including software architects, developers and operations/support staff.

Notation

The C4 model doesn't prescribe any particular notation. A simple notation that works well on whiteboards, paper, sticky notes, index cards and a variety of diagraming tools is as follows.

Person

Person

Software System

Software System

Container

Container

Component

Component

Relationship

Relationship

You can then use colour and shapes to supplement the diagram, either to add additional information or simply to make the diagram more aesthetically pleasing.

C4 and UML

Although the example diagrams above are created using a "boxes and lines" notation, the core diagrams can be illustrated using UML with the appropriate use of packages, components and stereotypes. The resulting UML diagrams do tend to lack the same degree of descriptive text though, because adding such text isn't possible (or easy) with some UML tools.

Here are three examples of a System Context, Container and Component diagram for comparison.

A system context diagram
A container diagram
A component diagram
System Context diagram
Container diagram
Component diagram
A system context diagram
A container diagram
A component diagram
A system context diagram
A container diagram
A component diagram

Diagram key/legend

Any notation used should be as self-describing as possible, but all diagrams should have a key/legend to make the notation explicit. This applies to diagrams created with notations such as UML, ArchiMate and SysML too, as not everybody will know the notation being used.

Diagram key

Notation, notation, notation

Although the C4 model is an abstraction-first approach and notation independent, you still need to ensure that your diagram notation makes sense, and that the diagrams are comprehensible. A good way to think about this is to ask yourself whether each diagram can stand alone, and be (mostly) understood without a narrative. You can use this short software architecture diagram review checklist to help.

Software architecture diagram review checklist

And here are some recommendations related to notation.

Diagrams

  • Every diagram should have a title describing the diagram type and scope (e.g. "System Context diagram for My Software System").
  • Every diagram should have a key/legend explaining the notation being used (e.g. shapes, colours, border styles, line types, arrow heads, etc).
  • Acronyms and abbreviations (business/domain or technology) should be understandable by all audiences, or explained in the diagram key/legend.

Elements

  • The type of every element should be explicitly specified (e.g. Person, Software System, Container or Component).
  • Every element should have a short description, to provide an "at a glance" view of key responsibilities.
  • Every container and component should have a technology explicitly specified.

Relationships

  • Every line should represent a unidirectional relationship.
  • Every line should be labelled, the label being consistent with the direction and intent of the relationship (e.g. dependency or data flow).
  • Relationships between containers (typically these represent inter-process communication) should have a technology/protocol explicitly labelled.

Examples

Here are some collections of example software architecture diagrams based upon the C4 model.

Big Bank plc

Big Bank plc
(System Landscape, System Context, Container, Component, Dynamic and Deployment)

Financial Risk System

Financial Risk System
(System Context)

Spring PetClinic

Spring PetClinic
(System Context, Container, Component, Dynamic and Deployment)

Message bus and microservices

Message bus and microservices
(Container and Dynamic)

Widgets Limited

Widgets Limited
(System Landscape, System Context and Dynamic)

Contoso University

Contoso University
(System Context, Container, Component and Dynamic)

Frequently asked questions

What's the background behind the C4 model?

The C4 model was created by Simon Brown, who started teaching people about software architecture, while working as a software developer/architect in London. Part of Simon's training course was a design exercise, where groups of people were given some requirements, asked to do some design, and to draw some diagrams to express that design.

Although this was a design focussed exercise, the wide variety of diagrams made it evident that the visualisation of ideas was a skill that most people sorely lacked. The C4 model is essentially a formalisation of how Simon used to visualise software architecture, which has evolved over the years.

What's the inspiration behind the C4 model?

The C4 model was inspired by the Unified Modeling Language and the 4+1 model for software architecture. In summary, you can think of the C4 model as a simplified version of the underlying concepts, designed to (1) make it easier for software developers to describe and understand how a software system works and (2) to minimise the gap between the software architecture model/description and the source code.

How old is the C4 model?

The roots of the C4 model, and the various diagram types within it, can be traced back to somewhere in the region of 2006, although the "C4" name came much later, around the end of 2011. It was created during a time where teams, influenced by the agile movement, were less than enthusiastic about using UML.

How many people use the C4 model?

The honest answer is that nobody knows. Simon has personally taught the C4 model to somewhere over 10,000 people in more than 30 countries; with conference talks, videos, books and articles reaching many more than this. Other people are also teaching, speaking and writing about the C4 model too. It's definitely being used though, in organisations ranging from startups to global household names.

Why "container"?

Terms like "process", "application", "app", "server", "deployable unit", etc all have associated implications, so the name "container" was chosen as a generic way to describe something in which components live. From one perspective, it's unfortunate that containerisation has become popular, because many software developers now associate the term "container" with Docker. From another perspective though, there is sometimes a nice parity between a container in the C4 model and an infrastructure (e.g. Docker) container.

While many teams successfully use the C4 model as is, feel free to change the terminology if needed.

Can we change the terminology?

This terminology (context, containers, components and code) works for many organisations and many types of software. However, sometimes an organisation will have an existing terminology that people are already familiar with. Or perhaps "components" and "classes" don't easily map on to the technology being used (e.g. functional languages often use the terms "module" and "function").

Feel free to modify the terminology that you use to describe software architecture at different levels of abstraction. Just make sure that everybody explicitly understands it.

How do you model microservices and serverless?

Broadly speaking, there are two options for diagramming microservices when using the C4 model.

  1. Microservices as software systems: If your software system has a dependency upon a number of microservices that are outside of your control (e.g. they are owned and/or operated by a separate team), model these microservices as external software systems that you can't see inside of.
  2. Microservices as containers: On the other hand, if the microservices are a part of a software system that you are building (i.e. you own them), model them as containers, along with any data stores that those microservices use. In the same way that a modular monolithic application is a container with a number of components running inside it, a microservice is simply a container with a (smaller) number of components running inside it.

The same is true for serverless functions/lambdas/etc; treat them as software systems or containers based upon ownership.

How do you diagram large and complex software systems?

Even with a relatively small software system, it's tempting to try and include the entire story on a single diagram. For example, if you have a web application, it seems logical to create a single component diagram that shows all of the components that make up that web application. Unless your software system really is that small, you're likely to run out of room on the diagram canvas or find it difficult to discover a layout that isn't cluttered by a myriad of overlapping lines. Using a larger diagram canvas can sometimes help, but large diagrams are usually hard to interpret and comprehend because the cognitive load is too high. And if nobody understands the diagram, nobody is going to look at it.

Instead, don't be afraid to split that single complex diagram into a larger number of simpler diagrams, each with a specific focus around a business area, functional area, functional grouping, bounded context, use case, user interaction, feature set, etc. The key is to ensure that each of the separate diagrams tells a different part of the same overall story, at the same level of abstraction.

See also Diagramming vs modelling for an alternative approach.

Will the diagrams become outdated quickly?

Due to the hierarchical nature of the C4 model, each diagram will change at a different rate.

  • System Context diagram: In most cases, the system context diagram will change very slowly, as this describes the landscape that the software system is operating within.
  • Container diagram: Unless you're building a software system that makes heavy use of microservices or serverless lambdas/functions/etc, the container diagram will also change relatively slowly.
  • Component diagram: For any software system under active development, the component diagrams may change frequently as the team adds, removes or restructures the code into cohesive components. Automating the generation of this level of detail with tooling can help.
  • Code diagram: The level 4 code (e.g. class) diagrams will potentially become outdated very quickly if the codebase is under active development. For this reason, the recommendation is to (1) not create them at all or (2) generate them on-demand using tooling such as your IDE.

Why doesn't the C4 model cover business processes, workflows, state machines, domain models, data models, etc?

The focus of the C4 model is the static structures that make up a software system, at different levels of abstraction. If you need to describe other aspects, feel free to supplement the C4 diagrams with UML diagrams, BPML diagrams, ArchiMate diagrams, entity relationship diagrams, etc.

The C4 model vs UML, ArchiMate and SysML?

Although existing notations such as UML, ArchiMate and SysML already exist, many software development teams don't seem to use them. Often this is because teams don't know these notations well enough, perceive them to be too complicated, think they are not compatible with agile approaches or don't have the required tooling.

If you are already successfully using one of these notations to communicate software architecture and it's working, stick with it. If not, try the C4 model. And don't be afraid to supplement the C4 diagrams with UML state diagrams, timing diagrams, etc if you need to.

Can we combine C4 and arc42?

Yes, many teams do, and the C4 model is compatible with the arc42 documentation template as follows.

  • Context and Scope => System Context diagram
  • Building Block View (level 1) => Container diagram
  • Building Block View (level 2) => Component diagram
  • Building Block View (level 3) => Class diagram

Does the C4 model imply a design process or team structure?

A common misconception is that a team's design process should follow the levels in the C4 model hierarchy, perhaps with different people on the team being responsible for different levels of diagrams. For example, a business analyst creates the system context diagram, the architect creates the container diagram, while the developers look after the remaining levels of detail.

Although you can certainly use the C4 model in this way, this is not the intended or recommended usage pattern. The C4 model is just a way to describe a software system, from different levels of abstraction, and it implies nothing about the process of delivering software.

Using C4 to describe libraries, frameworks and SDKs?

The C4 model is really designed to model a software system, at various levels of abstraction. To document a library, framework or SDK, you might be better off using something like UML. Alternatively, you could use the C4 model to describe a usage example of your framework, library or SDK; perhaps using colour coding to signify which parts of the software system are bespoke vs those provided for you.

Web applications; one container or two?

If you're building a server-side web application (e.g. Spring MVC, ASP.NET, Ruby on Rails, Django, etc) that is predominantly generating static HTML content, then that's a single container. If there's a significant quantity of JavaScript being delivered by the server-side web application (e.g. a single-page application built using Angular), then that's two containers. Here's an example.

Although, at deployment time, the server-side web application includes both the server-side and client-side code, treating the client and server as two separate containers makes it explicit that these are two separate process spaces, communicating via an inter-process/remote communication mechanism (e.g. JSON/HTTPS). It also provides a basis for zooming in to each container separately to show the components inside them.

Should the lines represent dependencies or data flow?

This is your choice. Sometimes diagrams work better showing dependency relationships (e.g. uses, reads from, etc), and sometimes data flow (e.g. customer update events) works better. Whichever you choose, make sure that the description of the line matches the direction of the arrow.

It's also worth remembering that most relationships can be expressed either way, and the more explicit you can be, the better. For example, describing a relationship as "sends customer update events to" can be more descriptive than simply "customer update events".

Is a Java JAR, C# assembly, DLL, module, etc a container?

Typically not. A container is a runtime construct, like an application; whereas Java JAR files, C# assemblies, DLLs, modules, etc are used to organise the code within those applications.

Is a Java JAR, C# assembly, DLL, module, package, namespace, folder etc a component?

Perhaps but, again, typically not. The C4 model is about showing the runtime units (containers) and how functionality is partitioned across them (components), rather than organisational units such as Java JAR files, C# assemblies, DLLs, modules, packages, namespaces or folder structures.

Of course, there may be a one-to-one mapping between these constructs and a component; e.g. if you're building a hexagonal architecture, you may create a single Java JAR file or C# assmebly per component. On the other hand, a single component might be implemented using code from a number of JAR files, which is typically what happens when you start to consider third-party frameworks/libraries, and how they become embedded in your codebase.

Diagramming vs modelling

As an industry, we've tended to prefer diagramming over modelling, primarily because the barrier to entry is relatively low, and it's seen as a much simpler task. When you're diagramming, you're typically creating one or more separate diagrams, often with an ad hoc notation, using tools (e.g. Microsoft Visio or a whiteboard) that don't understand anything about the semantics of your diagrams. The domain language of diagramming tools is really just boxes and lines, so you can't ask them questions such as "what dependencies does component X have?". Additionally, reusing diagram elements across diagrams is usually done by duplication (i.e. copying and pasting), thereby putting the responsibility on you to keep diagrams in sync when you rename such elements. It's worth noting here that the C4 model can be used irrespective of whether you are diagramming or modelling, but there are some interesting opportunities when you progress from diagramming to modelling.

With modelling, you're building up a non-visual model of something (e.g. the software architecture of a software system), and then creating different views (e.g. diagrams) on top of that model. This requires a little more rigour, but the result is a single definition of all elements and the relationships between them. This, in turn, allows modelling tools to understand the semantics of what you're trying to do, and provide additional intelligence on top of the model. It also allows modelling tools to provide alternative visualisations, often automatically.

One of the frequently asked questions (above) is about diagramming large and complex software systems. Once you start to have more than ~20 elements (plus the relationships between them) on a diagram, the resulting diagram starts to become cluttered very quickly. For example, image 1 (below) is a component diagram for a single container.

One approach to dealing with this is to not show all of the components on a single diagram, and instead create multiple diagrams, one per "slice" through the container (image 2, below). This approach can certainly help, but it's worth asking whether the resulting diagrams are useful. Are you going to use them and, if so, what are you going to use them for? Although the System Context and Container diagrams are very useful, Component diagrams for large software systems often have less value because they are harder to keep up to date, and you might find that very few people look at them anyway, especially if they are not included in documentation or presentations.

A large and cluttered diagram

Once you have more than ~20 elements on a diagram, the diagram starts to become cluttered very quickly.

A smaller diagram showing an individual slice

Creating multiple diagrams, one per "slice", can help, although the resulting diagrams tend to be very simple and increase the effort needed to keep them up to date.

An alternative visualisation

Rather than creating a diagram, you can use alternative visualisations instead. This visualisation shows the dependencies between components inside a container.

An alternative visualisation

And this alternative visualisation shows all of the elements and relationships in the model, filtered to show a subset of the model.

Often, the diagrams themselves aren't the end-goal, with teams using the diagrams to answer other questions that they have, such as, "what dependencies does component X have?". If this is the case, building a model will allow you to answer such questions, without the additional effort of creating a diagram. In other words, once you have a model, you can visualise it in a number of different ways (images 3 and 4, above), helping to answer the real questions that you are seeking to answer. Diagrams certainly are a fantastic way to communicate software architecture, but other visualisations can sometimes help answer the real underlying questions that you might have.

Metamodel

If you're interested in using the C4 model or building tooling to support it, here is some information about the basic metamodel.

Elements and relationships

Element type Parent Properties
Person None
  • Name*
  • Description
  • Location (Internal or External)
Software System None
  • Name*
  • Description
  • Location (Internal or External)
  • The set of containers that make up the software system
Container A software system
  • Name*
  • Description
  • Technology
  • The set of components within the container
Component A container
  • Name*
  • Description
  • Technology
  • The set of code elements (e.g. classes, interfaces, etc) that the component is implemented by
Code Element A component
  • Name*
  • Description
  • Fully qualified type
Relationship**
  • Description
  • Technology

* All elements in the model must have a name, and that name must be unique within the parent context.
** Relationships are permitted between any elements in the model, in either direction.

Views

View type Scope Permitted elements
1. System Context A software system.
  • Software systems
  • People
A System Context diagram
2. Container A software system
  • Software systems
  • People
  • Containers within the software system in scope
A Container diagram
3. Component A container
  • Software systems
  • People
  • Other containers within the parent software system of the container in scope
  • Components within the container in scope
A Component diagram
4. Code A component
  • Code elements (e.g. classes, interfaces, etc) that are used to implement the component in scope
A UML class diagram

On-site training

"Visualising software architecture with the C4 model" is a hands-on, half-day or full-day workshop with Simon Brown that focusses on the visualisation and communication of software architecture using the C4 model. The core of this workshop can be based upon a simple case study (an architecture kata) or your own software systems.

Abstract

It's very likely that the majority of the software architecture diagrams you've seen are a confused mess of boxes and lines. Following the publication of the Manifesto for Agile Software Development in 2001, teams have abandoned UML, discarded the concept of modelling and instead place a heavy reliance on conversations centered around incoherent whiteboard diagrams or shallow "Marketecture" diagrams created with Visio. Moving fast and being agile requires good communication, yet software development teams struggle with this fundamental skill. A good set of software architecture diagrams are priceless for aligning a team around a shared vision and for getting new-joiners productive fast.

This hands-on workshop explores the visual communication of software architecture and is based upon a decade of my experiences working with software development teams large and small across the globe. We'll look at what is commonplace today, the importance of creating a shared vocabulary, diagram notation, and the value of creating a lightweight model to describe your software system. The workshop is based upon the "C4 model", which I created as a way to help software development teams describe and communicate software architecture, both during up-front design sessions and when retrospectively documenting an existing codebase. It's a way to create maps of your code, at various levels of detail. Static structure, runtime and deployment diagrams are all covered, so you'll be able to tell different stories to different audiences. We'll wrap up the day by looking at the tooling landscape and diagram automation to keep your diagrams in sync with your source code.

Agenda (full-day version)
  • [09:00 - 09:15] Introductions
  • [09:15 - 11:00] Software diagramming exercise
  • [11:00 - 12:30] Review and feedback
    • Diagramming anti-patterns and typical problems
    • The "model-code gap"
  • [12:30 - 13:30] Lunch
  • [13:30 - 15:30] C4 model - core diagrams
    • Abstractions and creating a shared vocabulary with a ubiquitous language
    • An overview of the C4 model
    • Notation and tips for better diagrams
    • System Context diagrams
    • Container diagrams
    • Component diagrams
  • [15:30 - 16:00] C4 model - supplementary diagrams and other
    • C4 and UML
    • System Landscape diagrams
    • Dynamic diagrams
    • Deployment diagrams
    • Frequently asked questions
  • [16:00 - 16:45] Tooling
    • Diagrams vs models
    • Extracting software architecture information from code and "architecturally-evident coding styles"
  • [16:45 - 17:00] Discussion, questions and wrap-up
Agenda (half-day version)
  • [09:00 - 09:15] Introductions
  • [09:15 - 10:15] A summary of current diagramming practices
    • Diagramming anti-patterns and typical problems
    • The "model-code gap"
  • [10:15 - 12:15] C4 model - core diagrams
    • Abstractions and creating a shared vocabulary with a ubiquitous language
    • An overview of the C4 model
    • Notation and tips for better diagrams
    • System Context diagrams
    • Container diagrams
    • Component diagrams
  • [12:15 - 12:30] Discussion, questions and wrap-up
Duration

This workshop is best run as a full-day session, but the half-day version is sufficient for learning how to use the C4 model.

Learning outcomes

This workshop will give you some pragmatic, practical and lightweight techniques that you can apply to your work the very next day. You'll learn why most software architecture diagrams are meaningless, how to critique them, how to fix them and how to use the C4 model to create a simple yet powerful set of developer-friendly diagrams to describe software architecture.

Target audience

Software developers and architects; all levels of experience.

Pre-requisites

Some experience building software; no laptops needed.

Slides

The slides from the training course are available to download.

Visualising software architecture with the C4 model

Slides (full-day version; ~80MB .pdf file)
Visualising software architecture with the C4 model

Slides (half-day version; ~70MB .pdf file)

Pricing

The pricing model is a flat fee, rather than "per attendee", based upon location. The class size is flexible; the recommended number of people is between 10 and 20, although previous courses have been run for between 5 and 150 people. From a logistics point of view, all that is needed is a room with a projector and some whiteboards/flip chart paper. This workshop is occasionally run publicly via training providers or conferences but most are private, on-site workshops held directly with organisations.

Please e-mail Simon Brown for more details and pricing.

More information

The following resources are recommended if you're looking for more information about visualising software architecture and the C4 model. You can also join the "Software architecture for developers" Slack workspace to chat with others, ask questions, etc.

This is a recording of Simon Brown's talk at the OpenSlava conference in Bratislava, Slovakia during October 2017 (35 minutes).

This is a recording of Simon Brown's keynote at the Voxxed Days conference in Athens, Greece during May 2017 (60 minutes).

Software Architecture for Developers: Volumes 1 & 2

This is Simon Brown's Software Architecture for Developers (Volume 2) ebook, which is available to purchase from Leanpub as an ebook in PDF, EPUB and MOBI formats. It's a short guide to visualising, documenting and exploring your software architecture.

Simple Sketches for Diagramming Your Software Architecture

This is a short article written for Voxxed that summarises the C4 model.

A summary of the C4 model and tips for visualising software architecture

And here is a one-page cheat sheet (downloadable as an A3 poster in PDF format) that summarises how to visualise software architecture using the C4 model.

There are also some podcasts with Simon Brown, where he discusses the C4 model; including Software Engineering Daily and Software Engineering Radio.

Tooling

The following modelling and drawing tools can help create software architecture diagrams based upon the C4 model.

Structurizr

Structurizr

Structurizr is a collection of tooling to help you visualise, document and explore your software architecture. It's an implementation of the C4 model and allows you to create software architecture models using Java/C# or a browser-based editor, along with supplementary documentation using Markdown/AsciiDoc.

Modelling GUI-based Text-based Cloud On-premises

Structurizr Express

Structurizr Express

Structurizr Express lets you quickly create individual diagrams from the C4 model, using a JSON/YAML text format. Diagrams can be shared online, exported to a PNG file, or embedded in Atlassian Confluence.

There are also some additional tools that help can teams work with Structurizr Express; including fc4-tool and Fucturizr.

Diagramming Text-based Cloud On-premises

C4-PlantUML

C4-PlantUML

Ricardo Niepel has built some tooling that makes it easy to create C4 model diagrams in PlantUML.

Diagramming Text-based Cloud On-premises

PlantUML

Structurizr for Java/.NET + PlantUML

The open source Structurizr for Java and Structurizr for .NET libraries allow you to create a software architecture model and export it to the syntax used by PlantUML.

Modelling Text-based Cloud On-premises

Graphviz

Structurizr for Java + Graphviz

The open source Structurizr for Java library allows you to create a software architecture model and export it to the DOT syntax used by Graphviz.

Modelling Text-based On-premises

DGML

Structurizr.Dgml

When used in conjunction with the open source Structurizr for .NET library, Merijn de Jonge's Structurizr.Dgml project allows you to create zoomable/expandable diagrams with DGML (Directed Graph Markup Language), which is natively supported by Visual Studio.

Modelling Text-based On-premises

C4 Detonator

C4 Detonator

A web-based tool that allows you to create a C4 model and diagrams using a YAML syntax. See this YouTube video for a demo.

Modelling Text-based Cloud

Omnigraffle

OmniGraffle

Dennis Laumen has created a C4 stencil for OmniGraffle, that allows you to create diagrams using pre-built shapes.

Diagramming GUI-based On-premises

draw.io

draw.io

Tobias Hochgürtel has created a C4 plugin for draw.io, that allows you to create diagrams using pre-built shapes.

Diagramming GUI-based Cloud

Sparx Enterprise Architect

LieberLieber Software has built an extension for the C4 model, based upon the MDG Technology built into Sparx Enterprise Architect.

Modelling GUI-based On-premises
